Axle Boxes - Set of 4
4 assembled axle boxes
.
.
Key Features
- Enclosed Suspension - 12mm maximum travel when fully loaded.
- Roller Bearings - 12 mm inside diameter
- Enamelled and Gold Plated maker's plate on each axle box
- Weight of one axle box - 1.15 kg
- Can be secured to chassis using M8 screws both horizontally and vertically, for extra rigidity.
.
For overall dimensions - see picture gallery slider above. .
For drawings for interface compatibility for push fit purposes the bearing inner bore is Ø 12.00 mm x 12 mm long.
Description
This package consists of 4 assembled axle boxes.
Compatible with a 12+0.03mm diameter X 12mm long spigot.
Each axle box is made up of a number of precision components.
The body is machined from an aluminium billet, black anodised for both appearance and for corrosion resistance..
The fully sealed integral suspension within each axle box ensures smooth riding characteristics and is enclosed against ingress of dirt..
Periodic lubrication can be applied easily via the ball spring oiler on the outboard face above the maker's plates, this position negates the need for tipping or lifting the rolling stock..
The maker's plate s are secured with brass rivets and add that touch of finesse..
Why buy these axle boxes?
With their load carrying capability, ease of maintenance and appearance, we are sure these axle boxes will outperform alternative designs.
.
